Tractor Attachment Hydraulic Breaker

Price 101.0 INR/ piece

Get a Price/Quote

MOQ : 1 piece

Tractor Attachment Hydraulic Breaker Specification

Accessories Type
45 mm Heavy-Duty Chisel

Control System
hydraulic controls

Power Source
Tractor

Automation Grade
Hydraulic Control

Technology
Hydraulic

Features
250 600 BPM, 45 mm chisel, rapid 0.1 0.3 sec cycle, hydraulic operation, tractor compatibility

Machine Type
Tractor Attachment

Usage
Rock breaking, concrete breaking, asphalt breaking, excavation, trench preparation and demolition

Type
Tractor-Mounted Hydraulic Rock Breaker

Size
45 mm chisel diameter

Product Type
Hydraulic Rock Breaker Attachment

Weight
700 Kilograms (kg)

Color
Yellow

Function
Breaking hard rock, concrete, asphalt and compacted soil

Application
Construction, infrastructure, OFC trenching, pipeline, water management, mining, utilities

Voltage
250 600 BPM Volt (v)

About Tractor Attachment Hydraulic Breaker

Hydraulic Breaker Tractor Attachment

Hard rock, concrete, asphalt, and compact ground can create difficult sections during excavation and utility development. The Breaker is a hydraulic attachment developed to handle such conditions, providing concentrated impact for breaking hard surfaces before excavation and installation work.

Suitable for 60150 HP tractors, the attachment operates through a hydraulic system with lever-based controls for positioning and operation. Its 45 mm chisel, rapid impact cycle, and robust construction make it suitable for demanding infrastructure and utility works.

Key Features

High Impact Performance: Delivers 250-600 blows per minute for hard-surface breaking.
Heavy-Duty Chisel: 45 mm high-strength chisel concentrates impact force on the working surface.
Tractor Compatibility: Designed for tractors from 60-150 HP.
Hydraulic Operation: Uses a hydraulic system for breaker operation and control.
Precise Positioning: Lever-based controls allow controlled breaker positioning.
Rapid Cycle Time: 0.1-0.3 seconds per stroke supports continuous breaking operations.
Compact Attachment: Operating weight of 130 kg with a machine weight of 700 kg.

Applications

OFC and telecommunication trenching
Hard rock breaking
Concrete breaking and demolition
Asphalt and road cutting
Canal rehabilitation
Drainage development
Water pipeline installation
Underground utility works
Foundation breaking
Hard surface excavation
Obstacle removal
Construction and infrastructure projects
Mining and water management works

Technical Specifications

Parameter	Specification
Support Vehicle	Tractor
Horsepower	60-150 HP
Chisel Diameter	45 mm
Operating Weight	130 kg
Working Speed	250-600 BPM
Hydraulic Flow	40 LPM
Hydraulic Pressure	120 bar
Machine Weight	700 kg
Cycle Time	0.1-0.3 seconds per stroke
