Triple Chain Trencher - Gaja 300 XC

About Triple Chain Trencher - Gaja 300 XC

Product Description

The Wide Trenching Tractor-Mounted Trencher is engineered for large-scale infrastructure and utility projects requiring wide and deep trenching. Designed for tractors above 90 HP, it delivers trenching capacity up to 950 mm width and 1500 mm depth, ensuring superior productivity in diverse soil conditions. Powered by PTO with hydraulic controls, this detachable trencher combines durability, user-friendly operation, and transport flexibility. Ideal for defense, pipeline, energy, and civil utility works, it offers a long-lasting and cost-effective trenching solution.

Key Features

• Increased trenching capacity with width up to 950 mm and depth up to 1500 mm.

• Hydraulic cylinders for precise depth adjustment.

• Compatible with hard, medium, and soft soils.

• Detachable design easy to attach/detach from tractor.

• Inbuilt creeper mechanism for smooth operation with >90 HP tractors.

• Adjustable conveyor system for single-side debris accumulation.

• Pneumatic tyres for traction and road mobility.

• Lock/unlock transport mechanism for easy movement on roads.

• PTO driven for power and reliable performance.

• User-friendly, safe, durable, and easy to maintain.

•


Technical Specifications

• Support Vehicle: Tractor

• Horsepower: >90 HP

• Transmission Type: PTO / Hydraulic

• Drive Speed (Max): 40150 m/hr (depends on depth)

• Fuel Consumption: 68 L/hr

• Auxiliary Hydraulic Flow (Min): 60 LPM

• Trench Width (Customizable): Up to 950 mm

• Trench Depth (Adjustable): Up to 1500 mm

• Gross Weight: 3000 kg

• Overall Length: 5.2 m

• Overall Width: 2.8 m

• Overall Height: 1.7 m

Applications

• Defense: Trench warfare and fortification works.

• Water Management: Pipelines, canal irrigation, and drainage.

• Oil & Gas: Pipeline installation projects.

• Energy Sector: Solar & wind power projects, earthing, and cabling.

• Civil & Infrastructure: Underground utility lines (gas, power, water, telecom).
